By PolyPhaser
PolyPhaser: Broadband Surge Arrestor (698-2500 MHz)
Part Number:
ESXDC-DFM
Couldn't load pickup availability
PolyPhaser ESXDC-DFM is constructed with a female gender for the input and male for the output. This F/M 7/16 DIN to 7/16 DIN surge protecting component for RF has a let-through energy of 25mJ. PolyPhaser protection device ESXDC-DFM is designed with low passive intermodulation (PIM). This bulkhead 7/16 DIN PIM RF surge protector is rated for -155 dBc. The coaxial lightning surge arrestor is IP rated, it has an IP67 rating.
| Impedance | 50 Ohm |
| Connector In Series | 7/16 DIN |
| Connector In Gender | Female |
| Connector Out Series | 7/16 DIN |
| Connector Out Gender | Male |
| Minimum Frequency | 698 MHz |
| Maximum Frequency | 2.7 GHz |
| Maximum Input Power | 1,500 Watts |
| Direction | Bidirectional |
| Throughput Energy | 25,000 uJ |
| Type | |
|---|---|
| Connection type | |
| Wattage |
