7/16 DIN Male Right Angle to NEX10 Male RG402 Plenum (Flex Form Mini .141) Jumper, 25ft
Part Number:
123-14FMPDMRXM-25-P
Contact Us for Pricing & Availability
Couldn't load pickup availability
7/16 DIN Male Right Angle to NEX10 Male RG402 Plenum (Flex Form Mini .141) Jumper, 25ft
| CROSS REFERENCE | |
| Alternative To | TFT-402 |
| ELECTRICAL SPECIFICATIONS | |
| Frequency Range | 600-3000 Mhz |
| Impedance | 50 Ohm |
| PIM | -162dBc |
| Return Loss | ≤-27dB @3GHz, ≤-24dB @6GHz |
| VSWR | ≤1.1@0～3G，≤1.15@3～6G |
| ENVIRONMENTAL SPECIFICATIONS | |
| Operating Temperature | -55°C to +125°C |
| RoHS Compliance | Yes |
| Weather Standard | IEC 68 40/85/ 21 |
| PHYSICAL SPECIFICATIONS | |
| Connector A | 7/16 Male Right Angle |
| Connector B | NEX10 Male |
| Jacket Color | Blue |
| Outer Diameter | 4.15±0.10 mm |
