By 123eWireless
7/16 DIN Male to N Female RG402 Plenum (Flex Form Mini .141) Jumper, 6ft
Part Number:
123-14FMPDMNF-06-P
Contact Us for Pricing & Availability
Couldn't load pickup availability
7/16 DIN Male to N Female RG402 Plenum (Flex Form Mini .141) Jumper, 6ft
| ELECTRICAL SPECIFICATIONS | |
| Frequency Range | 600-3000 Mhz |
| Impedance | 50 Ohm |
| PIM | -162dBc |
| Return Loss | ≤-27dB @3GHz, ≤-24dB @6GHz |
| VSWR | ≤1.1@0～3G，≤1.15@3～6G |
| ENVIRONMENTAL SPECIFICATIONS | |
| Operating Temperature | -55°C to +125°C |
| RoHS Compliance | Yes |
| Weather Standard | IEC 68 40/85/ 21 |
| PHYSICAL SPECIFICATIONS | |
| Connector A | 7/16 Male |
| Connector B | N Female |
| Jacket Color | Blue |
| Outer Diameter | 4.15±0.10 mm |
Contact Us for Pricing & Availability
| Type | |
|---|---|
| Size | |
| Connection type |
If you have any questions about this product, please let us know by filling out the form below, and we will contact you as soon as possible.
