By 123eWireless
7/16 DIN Male to SMA Male RG401 (Flex Form 0.27") Jumper, 6ft
Part Number:
123-14FFDMSMAM-06-P
Contact Us for Pricing & Availability
Couldn't load pickup availability
7/16 DIN Male to SMA Male RG401 (Flex Form 0.27") Jumper, 6ft
| ELECTRICAL SPECIFICATIONS | |
| Frequency Range | up to 18Ghz |
| Impedance | 50 Ohm |
| PIM | -175dBc |
| Return Loss | ≤-27dB @3GHz, ≤-24dB @6GHz |
| ENVIRONMENTAL SPECIFICATIONS | |
| Operating Temperature | -55°C to +125°C |
| RoHS Compliance | Yes |
| Weather Standard | IEC 68 40/85/ 21 |
| PHYSICAL SPECIFICATIONS | |
| Inner Conductor | Silver-coated Copper |
| Insulation | Solid PTFE |
| Outer Conductor | Tin Soaked Copper Braid |
| Connector A | 7/16 Din Male Right Angle |
| Connector B | SMA MALE |
| Jacket Color | White |
| Outer Diameter | 7.00±0.15 mm |
Contact Us for Pricing & Availability
