4.3-10 Female 200 Watt Low PIM RF Load Termination
Part Number:
123-HFT200-160
Couldn't load pickup availability
4.3-10 Female 200 Watt , 6GHz, -160dBc Low PIM RF Load Termination
Wide Frequency Band 698-6000MHz
2G/3G/4G/LTE Coverage
Low VSWR
Widely used for In-building Solutions
| ELECTRICAL SPECIFICATIONS | |
| Average Power | 200 Watts |
| Frequency Range | 698-6000MHz |
| Impedance | 50 ohm |
| PIM | ≤-160dBc@2*43dBm |
| VSWR | ≤1.35 |
| ENVIRONMENTAL SPECIFICATIONS | |
| Operating Temperature | -30C to +65C |
| PHYSICAL SPECIFICATIONS | |
| Gender | Female |
| Connector A | 4.3-10 Female |
| Frequency range | |
|---|---|
| Connection type | |
| Wattage |
