Kaelus: AWS/WCS-PCS Quad Diplexer, No DC/AISG
Part Number:
DBC0129F1V1-1
Couldn't load pickup availability
Kaelus: AWS/WCS-PCS Quad Diplexer, No DC/AISG
Kaelus world proven outdoor solutions provide strong RF performance coupled with rugged features. The DBC0129 dual band combiner combines the AWS/WCS band with PCS. The DBC0129 can be used at either the BTS or antenna end of the feeder.
- Designed for multi-band, co-located sites
- Multiple DC/AISG bypass configurations available with built-in lightning protection
- Suitable for outdoor and indoor applications
- 4x4 MIMO LTE ready
- Wall or mast mounting
- QUAD 4 in / 8 out
| Band Name | AWS/WCS | PCS | |||||||||||||
| Passband | 1695 - 1780MHz, 2110 - 2360MHz | 1850 - 1995MHz | |||||||||||||
| Insertion loss | < 0.2dB typical, < 0.3dB maximum | < 0.25dB typical, < 0.38dB maximum | |||||||||||||
| Return loss | > 20dB | ||||||||||||||
| Maximum input power | 100W (average) / 1kW (PEP) | ||||||||||||||
| Intermodulation products | -160dBc maximum at 2 x 43dBm TX Carrier | ||||||||||||||
| Rejection PCS | > 40dB | N/A | |||||||||||||
| Rejection AWS/WCS | N/A | > 40dB | |||||||||||||
AT&T SKU:
ANT.16702
| Connection type |
|---|
