7/16 DIN Male Right Angle Solder Type Connector for LMR240 Cable
Part Number:
123-14DMR-S
Contact Us for Pricing & Availability
Couldn't load pickup availability
7/16 DIN Male Right Angle Solder Type Connector for LMR240 Cable
- Application: Connector for LMR240 cable (model SA240 or equivalent).
The 7/16 Din Male Right Angle Solder Type Connector is specifically designed for use with 1/4" Flexible Low Loss Coax Standard cable (model LMR240 or equivalent). This connector is ideal for applications that require reliable, low-impact signal connections in telecommunications systems, data communications, and other signal transmission applications.
| ELECTRICAL SPECIFICATIONS | |
| Frequency Range | DC-6GHz |
| Impedance | 50 Omhs |
| PIM | < -160 dBc |
| VSWR | < 1.2 |
| ENVIRONMENTAL SPECIFICATIONS | |
| Operating Temperature | -65°C to ~165°C |
| Weather Standard | IP68 |
| PHYSICAL SPECIFICATIONS | |
| Gender | Male |
| Inner Conductor | Phosphorus-Bronze Silver Plating |
| Mating Cycles | >100 |
| Options | Solder Type |
| Outer Conductor | Brass Copper-Tin-Zinc Plating |
| Connector A | QMA Male |
Contact Us for Pricing & Availability
| Type | |
|---|---|
| Size | |
| Connection type |
